Designer: Roberto Semprini
Architectural Waste Collection for High-Traffic Environments
Fluxus is a high-capacity commercial trash receptacle designed by Roberto Semprini.
Its broad, sculptural profile coordinates with the Fluxus seating, bicycle-parking, and signage collections while providing significant waste capacity for busy public environments.
Published Capacity and Dimensions
- Capacity: approximately 23.8 U.S. gallons / 90 liters
- Height: approximately 45.3 in / 1,150 mm
- Length: approximately 22.4 in / 570 mm
- Width: approximately 22 in / 560 mm
- Published weight: approximately 114.6 lb / 52 kg
- Ashtray capacity: approximately 0.07 U.S. gallon / 0.25 liter each
Materials and Finishes
- Galvanized and powder-coated steel
- Custom RAL colors
- Corten steel upon request
- Integrated ash-management options
Specification Text
Provide LAB23 Fluxus commercial trash receptacle designed by Roberto Semprini, with approximately 90-liter capacity, formed steel exterior structure, removable internal waste container, specified integrated ash receptacle, selected powder-coated or Corten finish, lockable servicing system, and permanent anchoring.
Frequently Asked Questions
Gallery
Fluxus Bin
The load-bearing structure of the bin is made in steel sheet of 30/10 thickness. Inside the bin, a strong support of 30/10 thickness, on which there are 4 threaded inserts M8 for the fixing of the structure of the bin, is welded. The bin has a front part, which can be opened, and a back that can’t. Both parts are made in steel sheet of 15/10 thickness, supported by profiles of 30/10 thickness. On the door there is a triangular key lock. On the base of the bin, there are 4 holes of 11 mm diam. for the fixing to the ground through specific bolts (not provided). Inside the bin there is a container in galvanized steel sheet of 10/10 thickness, which is also polyester-powder coated. On the upper part there are 2 oval holes serving as handles and two holes of 10 mm diam. for the insertion of the elastic band. On the side of the load-bearing structure there is an ashtray, and on demand another can be added to the other side.
This product is entirely made in Italy from steel subjected to an electrolytic galvanising cycle and subsequently painted with PP powders with Ral colour of your choice.
As an alternative to steel EN10111DD11, the production in corten is also available, on demand. In this case the material is treated with a specific oxidation process.
The galvanized steel used is steel EN10346DX51D+Z and, unless otherwise stated, is not painted.
The load-bearing structure of the bin is made in steel sheet of 30/10 thickness. Inside the bin, a strong support of 30/10 thickness, on which there are 4 threaded inserts M8 for the fixing of the structure of the bin, is welded. The bin has a front part, which can be opened, and a back that can’t. Both parts are made in steel sheet of 15/10 thickness, supported by profiles of 30/10 thickness. On the door there is a triangular key lock. On the base of the bin, there are 4 holes of 11 mm diam. for the fixing to the ground through specific bolts (not provided). Inside the bin there is a container in galvanized steel sheet of 10/10 thickness, which is also polyester-powder coated. On the upper part there are 2 oval holes serving as handles and two holes of 10 mm diam. for the insertion of the elastic band. On the side of the load-bearing structure there is an ashtray, and on demand another can be added to the other side.
This product is entirely made in Italy from steel subjected to an electrolytic galvanising cycle and subsequently painted with PP powders with Ral colour of your choice.
As an alternative to steel EN10111DD11, the production in corten is also available, on demand. In this case the material is treated with a specific oxidation process.
The galvanized steel used is steel EN10346DX51D+Z and, unless otherwise stated, is not painted.
